HIGRO

HIGRO special doors

The door is designed for use in residential, public and industrial buildings and warehouses as an internal door closing the opening in the internal wall between the rooms. The door is designed for interiors where permissible relative air humidity is up to 90% and temperature does not exceed 65oC. The door cannot be directly exposed to water.

The door is particularly suitable for rooms with increased relative humidity and temperature, in accordance with the manufacturer's instructions for use.If the door is installed in rooms with a high concentration of chlorine, there is a risk of corrosion on fittings, panels and stainless steel portholes.

PARAMETERS

• mechanical class: 2nd class of mechanical strength requirements, i.e., medium operating conditions resistance to climatic conditions
• 3rd class according to PN-EN 12219:2002
• doors approved for sale in accordance with PN-EN 14351-2:2018

LEAF CONSTRUCTION

• Doors in the non-rebate system. The leaf construction consists of a polyurethane frame reinforced with plywood, clad on both sides with 2 mm HPL laminate. The filling is a special thermal insulation insert.

STANDARD EQUIPMENT

• mortise lock single-point, spacing 72 mm; lock for bathroom lock, spacing 78 mm
• powder-coated stainless steel hinges in grey RAL 7047 (2 pcs.); it is possible to paint the hinges in another RAL colour according to the customer's order
• design W04: porthole BMD3 lacomat glass

FRAMES

• Metal fixed, rebate-free door frame with rebate seal made of 1,5 mm galvanised sheet metal. Metal adjustable frame without rebate in galvanised sheet 1.5 mm thickness in the same colour as the leaf surface.
• Adjustable metal frame without rebate made of galvanised sheet 1.5 mm thick in the same colour as the leaf surface.

OPTIONAL ACCESSORIES

• overhead door closer
• drop seal
• stainless steel ventilation grill
• Higro handle and Higro bottom rosette in stainless steel
• stainless steel panels glued at the bottom of the leaf or at handle height
• additional ZOX adjustment for rebate-free adjustable frame (increase in wall width 650 mm)
• stainless steel porthole - lacomat/transparent glass (surcharge for version W04)

DOOR DIMENSIONS

HIGRO fixed metal frame:

• Single leaf doors:
  ‘60’ - 702x2088 mm, ‘70’ - 802x2088 mm, ‘80’ - 902x2088 mm, ‘90’ - 1002x2088 mm
  max. width ‘100’ - 1102 mm, max. height 2288 mm
  doors lower by 55 mm or 100 mm - no extra charge
  doors with height 2188 mm
  door height 2288 mm

HIGRO adjustable metal frame:

• Single leaf doors: ‘60’ - 722x2098 mm, ‘70’ - 822x2098 mm, ‘80’ - 922x2098 mm, ‘90’ - 1022x2098 mm
  max. width ‘100’ - 1122 mm, max. height 2298 mm
  doors lower by 55 mm or 100 mm - no extra charge
  doors with a height of 2198 mm
  doors with a height of 2298 mm
